NEW, 4" MANUAL + FULL CNC HORIZONTAL BORING MILL
Brand
Not Specified
Model
Type
Boring Mills, Horizontal, Table Type
Stock #
17534
Condition
New
Year
2024
Location
HOUSTON, Texas
United States
Specifications
Equipped With
SPINDLE DIAMETER: 4.33"
SPINDLE TAPER: ISO 50
SPINDLE SPEEDS: 10 - 1100 RPM
SPINDLE MOTOR: 20 HP
MAXIMUM SPINDLE TORQUE: 1069 FT.-LBS.
FACING HEAD DIAMETER: 25.59"
FACING HEAD SPEEDS: 7 - 165 RPM
MAXIMUM FACING HEAD TORQUE: 1604 FT.-LBS.
MAXIMUM FACING HEAD BORING DIAMETER: 25.59"
TABLE SIZE: 49.2" X 55.1"
MAXIMUM TABLE LOAD CAPACITY: 11,000 LBS.
TABLE CROSS TRAVEL (X): 70.8"
TABLE LONGITUDINAL TRAVEL (Z): 63"
HEADSTOCK VERTICAL TRAVEL (Y): 55.1"
SPINDLE AXIAL TRAVEL (W): 23.6"
FACING HEAD SLIDE TRAVEL (U): 7.8"
ROTARY TABLE (B): 360 DEGREES
MAXIMUM TABLE ROTATION SPEED: 1.3 RPM
FEEDS (X, Y, Z, W): 0.098 - 78.74 IPM
FEEDS (U): 0.039 - 19.68 IPM
RAPIDS (X, Y, Z): 197 IPM
RAPIDS (W): 118 IPM
RAPIDS (U): 19 IPM
POSITIONING ACCURACY (X, Y, Z): 0.0098"
POSITIONING ACCURACY (B): 10 ARC SEC
REPEATABILITY (X, Y, Z): 0.00059"
REPEATABILITY (B): 6 ARC SEC
OAD (LXWXH): 216.5" X 161.4" X 157.5"
WEIGHT (APPROXIMATE): 41,800 LBS.
EQUIPPED WITH:
FANUC 32i CNC CONTROL WITH MANUAL OPERATION PANEL FOR SPINDLE SPEEDS, INDIVIDUAL AXIS RAPID AND FEED RATE CONTROLS
COOLANT AND CHIP CONTROL PACKAGE WITH TABLE GUARD
FANUC ALPHA SERIES SERVO MOTORS ON X, Y, Z AND W AXES
CLOSED LOOP LINEAR SCALES ON X, Y, AND Z AXES
BUILT-IN ENCODER MOTOR ON W AXIS
ANGLE ENCODER ON B AXIS
BUILT-IN FACING HEAD
BUILT-IN ROTARY TABLE
OUTBOARD SUPPORT
BORING BAR
*Available upon request: Detailed proposal with construction characteristics, additional detailed photos, options list and more.
**Machinery is out of stock with 6 month delivery/
SPINDLE TAPER: ISO 50
SPINDLE SPEEDS: 10 - 1100 RPM
SPINDLE MOTOR: 20 HP
MAXIMUM SPINDLE TORQUE: 1069 FT.-LBS.
FACING HEAD DIAMETER: 25.59"
FACING HEAD SPEEDS: 7 - 165 RPM
MAXIMUM FACING HEAD TORQUE: 1604 FT.-LBS.
MAXIMUM FACING HEAD BORING DIAMETER: 25.59"
TABLE SIZE: 49.2" X 55.1"
MAXIMUM TABLE LOAD CAPACITY: 11,000 LBS.
TABLE CROSS TRAVEL (X): 70.8"
TABLE LONGITUDINAL TRAVEL (Z): 63"
HEADSTOCK VERTICAL TRAVEL (Y): 55.1"
SPINDLE AXIAL TRAVEL (W): 23.6"
FACING HEAD SLIDE TRAVEL (U): 7.8"
ROTARY TABLE (B): 360 DEGREES
MAXIMUM TABLE ROTATION SPEED: 1.3 RPM
FEEDS (X, Y, Z, W): 0.098 - 78.74 IPM
FEEDS (U): 0.039 - 19.68 IPM
RAPIDS (X, Y, Z): 197 IPM
RAPIDS (W): 118 IPM
RAPIDS (U): 19 IPM
POSITIONING ACCURACY (X, Y, Z): 0.0098"
POSITIONING ACCURACY (B): 10 ARC SEC
REPEATABILITY (X, Y, Z): 0.00059"
REPEATABILITY (B): 6 ARC SEC
OAD (LXWXH): 216.5" X 161.4" X 157.5"
WEIGHT (APPROXIMATE): 41,800 LBS.
EQUIPPED WITH:
FANUC 32i CNC CONTROL WITH MANUAL OPERATION PANEL FOR SPINDLE SPEEDS, INDIVIDUAL AXIS RAPID AND FEED RATE CONTROLS
COOLANT AND CHIP CONTROL PACKAGE WITH TABLE GUARD
FANUC ALPHA SERIES SERVO MOTORS ON X, Y, Z AND W AXES
CLOSED LOOP LINEAR SCALES ON X, Y, AND Z AXES
BUILT-IN ENCODER MOTOR ON W AXIS
ANGLE ENCODER ON B AXIS
BUILT-IN FACING HEAD
BUILT-IN ROTARY TABLE
OUTBOARD SUPPORT
BORING BAR
*Available upon request: Detailed proposal with construction characteristics, additional detailed photos, options list and more.
**Machinery is out of stock with 6 month delivery/
