Used, 30" x 360" Lehmann Hollow Spindle Lathe with 9.57" Spindle Bore
Brand
LEHMANN
Model
2516
Type
Lathes, Oil Field & Hollow Spindle
Stock #
19917
Condition
Used
Year
1943
Location
Houston, Texas
United States
Specifications
Equipped With
Swing Over Bed: 30"
Swing Over Cross Slide: 16"
Distance Between Centers: 360"
Bed Width: 27.5"
Spindle Speeds: 5 - 150 RPM
Spindle Motor: 25 HP
Spindle Bore: 9.57"
Spindle Mount: Cylindrical (Lehmann)
Inch Threading: 1 - 30 TPI
Tailstock Taper: Morse #6 (Live)
Tailstock Quill Diameter: 5.5"
Electrics: 460 V / 3 Ph
Weight (approximate): 25,000 Lbs.
Equipped with:
Front / Rear 24" Cushman 4-Jaw Chucks with 9.57" Thru-Holes
Taper Attachment
Note: Soft Bed (in excellent condition)
NOTE: ALL SPECIFICATIONS SUBJECT TO VERIFICATION
