Used, 32" x 120" Lehmann Hydratrol Hollow Spindle Lathe with 16.5" Spindle Bore
Brand
LEHMANN
Model
Hydratrol
Type
Lathes, Oil Field & Hollow Spindle
Stock #
19916
Condition
Used
Year
1942
Status
For Sale
Location
Houston, Texas
United States
Specifications
Equipped With
Swing Over Bed: 32"
Swing Over Cross Slide: 22.5"
Total Bed Length: 168"
Distance Between spindle nose and turret or optional TAILSTOCK: 135"
Bed Width: 27.5"
Spindle Speeds: (12) 5 - 150 RPM
Spindle Motor: 40 HP
Spindle Bore: 16.5"
Spindle Mount: Cylindrical
Inch Threading: 5/8 - 72 TPI
Feedrates: 0.0055 - 0.64 IPR
Leadscrew Diameter: 2.125"
Electrics: 460V / 3 Ph
Equipped with:
Threading on Front Carriage
4-Sided Tool Post
Taper Attachment (Both Saddles)
Note: Machine Fully Reconditioned
NOTE: ALL SPECIFICATIONS SUBJECT TO VERIFICATION
