Used, HEM WF190LA-DC Horizontal Automatic Bandsaw

Brand
HE&M

Model
WF190LA-DC

Type
Saws, Band, Horizontal, Dual Column

Stock #
20081

Condition
Used

Year
1998

Status
For Sale

Location
Houston, Texas
United States

Specifications

Equipped With

Rectangular Capacity: 25" x 44"
Round Capacity: 25"
Blade Speeds: 70 - 500 SFPM
Blade Motor: 15 HP
Hydraulic Motor: 5 HP
Blade Size: 29' x 2" x 0.063"
Permanent Arm Tilt: 9.2 Deg.
OAD (Approximate): 175" x 119" x 119" High
Weight (Approximate): 13,500 Lbs.

HEM Saw offers the WF190LA-DC-C wide-flange band saw machine. This horizontal automatic band saw is designed specifically for cutting wide-flange beams with capacities ranging from 25” high to 44” wide.
It features a dual-column design, and the pair of huge columns provide for an exceptional amount of strength and precision for fast and accurate cutting results.
The WF190LA-DC-C uses a 15 HP motor and another 5 HP motor for the hydraulics. The machine is designed to accommodate a 26’9” blade length x 2” blade width x .063” blade thickness. It can be set to a 9.2 degree permanent arm tilt.

Note: All Specifications Subject to Verification
